- Effectively remove floor finish without expensive stripping chemicals with the 28 in / 700 mm orbital cleaning head option , which includes a 2 , 000 hour / 3-year isolator warranty.
- Clean virtually any hard surface condition and maximize your return on investment with a wide range of cleaning heads , including a 28 in / 700 mm orbital option.
- Virtually eliminate the need for caustic floor stripping chemicals with the use of the orbital scrub head which allows for chemical-free floor finish removal.
- Improve operator ergonomics through updated and enhanced controls that put the propel switch and speed setting within easy reach.
- Evenly and effectively remove floor finish with one of the highest orbital standard down pressure settings at 170 lb / 77 kg.
- Prevent safety issues related to overfilling batteries with Smart-Fill automatic battery watering , which fills batteries correctly every time.
Coding & Country of Origin
Country of Origin
United States
UNSPSC
47121605
Drive System Properties
Pad Assist or Traction Drive
Traction Drive
Charger Properties
Charger Type
Onboard
Cleaning System Properties
Cleaning Path (Inches)
28
Recommended Pad/Brush Size (Inches)
14" x 28"
Scrubber Head Type
Orbital
Brush Speed (RPM)
2200
Down Pressure 2 - Medium (Pounds)
140
Down Pressure 3 - High (Pounds)
170
Down Pressure 1 - Low (Pounds)
110
Appearance Properties
Color
Blue
Manufacturer Information
Manufacturer Item #
T500-700-O
Manufacturer Name
Tennant
Electrical Specification Properties
Power Source
Battery
Cord Length (Feet)
0
Vacuum Motor Horsepower
0.63
Vacuum Motor Watts
4700
Vacuum Motor Voltage
24
Pad/Brush Motor Horsepower
0.75
Pad/Brush Motor Watts
5500
Pad/Brush Motor Voltage
24
Battery Properties
Battery Type
Wet
# of Batteries
4
Battery (aH)
225
Battery Run Time (Hours:Minutes)
Up to 4.9 Hours
Battery Included
Yes
Solution & Recovery System Properties
Recovery Tank Capacity
27
Solution Tank Capacity
22.5
Water Lift (Inches)
46
Speed & Productivity Properties
Max Theoretical Productivity (Sq Ft per Hour)
30800
Practical Productivity (Sq Ft per Hour)
22286
Warranty Information
Parts Warranty (Months)
36
Labor Warranty (Months)
24
Trip Warranty (Months)
6
Weights & Dimensions
Product: Length (Inches)
58.5
Product: Width (Inches)
28
Product: Height (Inches)
43.3
Product: Weight (Pounds)
660
Packaged: Length (Inches)
73
Packaged: Width (Inches)
43
Packaged: Height (Inches)
52
Packaged: Weight (Pounds)
685
General Equipment Properties
Sound Level (dBa)
67
Scrubber
Walk Behind
Hazardous Material
OSHA Hazardous Material
false
DOT Hazardous Material
false
